Greenlee 854DX Single-Shoe Electric Conduit Bender, 1/2"-2" EMT/IMC/Rigid
ELECTRIC CONDUIT BENDER 854DX
1/2"-2"EMT,IMC AND RIDGID
List Price: $12,689.00
Call for availability (0 on hand)
Product Images
Primary
Images provided by GREENLEE
Description
The Greenlee 854DX Electric Conduit Bender uses one shoe to bend 1/2 in. through 2 in. EMT, IMC, and Rigid conduit — covering the conduit sizes most electricians need from a single setup. Centerline bend radius runs 4.25 in. (108 mm) to 9 in. (228.6 mm) depending on conduit type and angle.
Solid-state electronics are rated for over 1,000,000 bends. The 120 VAC unit ships with a 20-amp GFCI-protected receptacle, weighs 550 lbs, and is built in the USA.
Features
- One shoe bends 1/2 in. through 2 in. EMT, IMC, and Rigid conduit
- Solid-state electronics rated for over 1,000,000 bends
- 20-amp GFCI-protected receptacle for jobsite power safety
- Made in USA
Technical Specifications
- Voltage
- 120 VAC
- Amperage
- 20 A (GFCI Protected)
- Conduit Capacity
- 1/2" to 2" EMT, IMC, and Rigid (single shoe)
- Centerline Bend Radius
- 4.25" - 9" (108-228.6 mm)
- Tool Weight
- 550 lbs
- Bend Cycle Rating
- 1,000,000+ bends (solid-state electronics)
General Information
- Item Number
- 854DX
- Categories
- Electrical Supplies, Power Tools
- Subcategories
- Conduit & Cable Mgmt
- Manufacturer
- GREENLEE TOOL CO
- Vendor Item #
- 854DX
- Manufacturer Code
- GTC
- UPC
- 783310026709
- Alpha Code
- BENDER
- Class
- 110
- Availability
- Call for availability (0 on hand)
Dimensions & Weight
- Weight
- 550.00 lbs
- Dimensions
- 0.00" L × 0.00" W × 0.00" H
